Titanium alloy medium frequency induction heating equipment

Product use: Suitable for heating large diameter pure titanium, aluminum alloy, stainless steel and other metal workpieces from q20-250mm

Main technical parameters of alloy billet induction heating equipment

Workpiece specification: Medium 20-250mm

Power supply: 200-5000kW

Single line output: up to 10t/h Applicable workpieces: large diameter titanium, nickel based alloys, stainless steel, aluminum alloys, etc. Applicable processes: billet reheating, cold billet heat transfer, rolling, forging, extrusion

Heating temperature: up to 1200C

Forever's titanium, titanium alloy, and nickel based alloy induction heating equipment is suitable for medium to medium sizes of 20-250mm, especially for large diameters above 90 degrees Celsius, with heating temperatures up to 1200C,

The output of a single production line can reach up to 10t/h. Used for reheating large diameter titanium, nickel based alloys, stainless steel, aluminum alloys, and other billets, as well as cold billet heat transfer. Meet the high-performance requirements of industries such as rolling, forging, and extrusion. Under the process of temperature equalization in a non resistance furnace, only induction heating is used to ensure that the radial and cross-sectional temperature differences of the workpiece are less than 25 ° C when it is taken out of the furnace. For some special applications, the radial and cross-sectional temperature differences can be ensured to be less than 10 ° C.

Some production lines with high requirements and special processes have integrated temperature closed loops to ensure precise temperature control throughout the heating process without overheating.

Different device structural forms can be applied to continuous production and single piece production.

Provide free finite element process simulation solutions for large-scale projects.

1. Technical after-sales service with professional engineers for overseas equipment.

2. On site technical service guidance and training for operators to proficiently operate the entire equipment.

3. The warranty period is 12 months and online permanent service is provided.
